Tektronix 5B12N Signal Generator

In stock

The Tektronix 5B12N Signal Generator is a versatile instrument designed for a wide range of applications in industrial control systems. It offers precise signal generation capabilities, making it ideal for testing, calibration, and troubleshooting in various industries.

Frequency Range:0.1 Hz to 20 MHz

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary

Output Amplitude:±20 Vp-p into 50Ω load

Resolution:14-bit vertical resolution

Sampling Rate:200 MSa/s

Bandwidth:DC to 20 MHz

Phase Shift:±90°

Output Impedance:50Ω

The Tektronix 5B12N Arbitrary Function Generator provides advanced signal generation capabilities, enabling users to create precise waveforms for testing and calibration purposes. Its wide frequency range and high-resolution output make it suitable for demanding industrial applications.

This module supports a variety of waveform types including sine, square, triangle, ramp, pulse, and user-defined arbitrary waveforms, providing unparalleled flexibility for different use cases.

With its high sampling rate of 200 MSa/s and 14-bit vertical resolution, the Tektronix 5B12N ensures accurate and reliable signal generation, essential for precision testing and measurement tasks.

The phase shift capability of ±90° allows for fine-tuning of signal characteristics, making it an indispensable tool for engineers and technicians working in industrial automation and research.

Designed for durability and reliability, the Tektronix 5B12N is built to withstand the rigors of industrial environments, ensuring consistent performance over time.

TEKTRONIX 5B12N
